Gemi Sahibi
Adalady Shipping Ltd.Company IMO 6069057
80 Broad Street Monrovia Liberia
Gemi Yönetimi
Adaline Denizcilik San. ve Tic. Ltd. Şti.Company IMO 5810421
Barbaros Mh. Al Zambak Sk. Varyap Meridian Grand Tower A-Blok D159 Ataşehir – İSTANBUL
Tic. Sic. No: 930579 Kozyatağı V.D. : 007 062 3902
| SHIP’S NAME |
ADALADY |
| EX.NAME |
NEW AUDACITY |
| CALL SIGN |
5 L T R 9 |
| PORT OF REGISTERY FLAG |
MONROVIA LIBERIA |
| BUILD PLACE / YEAR |
HUANGHAI SHIPBULDING CO.LTD. / CHINA-2013 |
| IMO NO |
9664160 |
| MMSI NO |
636024660 |
| CLASS / NO |
B / V |
| P&I |
THE LONDON P&I CLUB |
| HULL&MACHINERY |
ALIANZ GROUP |
| TYPE OF SHIP |
GENERAL CARGO VESSEL |
| SEA SPEED/CONSP |
BALLAST 12,5 KNT LOAD 11.0KNT |
|
LOADED 10,5 KTS / 15 MTN |
|
| L.O.A. |
119.99 M |
| L.B.P. |
113.80 M |
| MOULDED DEPTH/BREATH |
11.40M/22.00M |
| AIR DRAFT |
38,60 M |
| GRT |
9037 RT |
| NRT |
4396 RT |
| SUEZ GRT/ NRT |
|
| PANAMA GRT REG.NO |
|
| LIGHT SHIP |
3921MT |
| T.P.C. |
23,7 |
| F.W.A. |
184 MM |
| TOTAL BALLAST CAP. |
5265 M³ |
| TOTAL F/O CAP. |
486,46 M³ |
| TOTAL D/O CAP. |
93,15 M³ |
| TOTAL L/O CAP. |
47,44 M³ |
| TOTAL FW CAP. |
221,67 M³ |
| PROPELLER |
FIXED RIGHT HANDED |
| FREEBOARD BALLAST LADEN |
6,15 M / 2.91 M |
| HATCH COVER |
MC GREGOR HYDROLIC |
| MAIN ENG.&POWER |
STX 6L35MC6 |
| GEN.& POWER |
2 X 530 KW |
| BOW THRUST. POW. |
NIL |
| SHAFT GEN.& POW |
NIL |
| EMG.GEN.& POW |
70 KW |
| CRANES |
NO 1-2 36 MTS |
|
|
|
| HOLDS DIMENSIONS |
NO1 FWD W6.6xL22.2XH10.4 M |
|
NO2 FWD W15.6xL28.8xH10.4 |
|
|
NO3 W15.6xL28.8xH10.4 |
|
|
NO1 AFT W15.6 |
|
| HATCH DIMENSIONS |
NO1 13,86Mx13,40M |
|
NO2 26.95Mx18.00M |
|
|
NO3 18.48×18.00M |
|
| HOLD TANK TOP STR |
15 MT/M2 |
| HATCH TT |
2.6 M2 |
|
|
|
| MAIN DECK TT |
3 MT/M2 |
|
|
|
| HOLD VENTILATION |
NO1 2×130 M3/H |
|
NO2 2×145 M3/H |
|
|
NO3 2×145 M3/H |
| LOAD LINE |
FREEBOARD |
DRAFT |
DISP. |
DEADWEIGH |
| SUMMER | 2,918 | 8,500 | 17481 | 13559 |
| TROP FW |
2,516 |
8,902 |
18011 |
13989 |
| FRESH WATER |
2,734 |
8,684 |
17980 |
13980 |
| TROPICAL |
2,741 |
8,677 |
17984 |
13984 |
| WINTER |
3,095 |
8,323 |
17155 |
13370 |
| COMPARTMENT |
GRAIN M³ |
GRAIN CBTF |
BALE M³ |
BALE CBTF |
| HOLD NO 1 |
3629,26 |
128163,68 |
3551,14 |
125404,96 |
| HOLD NO 2 |
7364,87 |
260083,02 |
7206,33 |
254484,34 |
| HOLD NO 3 |
4724,69 |
166847,70 |
4622,98 |
163255,92 |
| TOTAL | 15718,83 |
555094,40 |
15380,45 |
543145,22 |
